32A Spring Lever Push Fit Reusable 3 Way Wire Connectors

$2.00

Description Color: Clear and Orange 3 Way: 20 x 16 x 19 mm / 0.78" x 0.63" x 0.74" (LxWxH) Max. Voltage: EN 400 V Current Intensity: EN 32 A Max. Isolation: 4 kV Max. Continuous Service Temperature: 85°C Strip Length: 9-10mm Compact connector with levers Solid conductor size 0.08...

Real time Visitor right now

32A Spring Lever Push Fit Reusable 3 Way Wire Connectors

32A Spring Lever Push Fit Reusable 3 Way Wire Connectors

Description

  • Color: Clear and Orange
  • 3 Way: 20 x 16 x 19 mm / 0.78" x 0.63" x 0.74" (LxWxH)
  • Max. Voltage: EN 400 V
  • Current Intensity: EN 32 A
  • Max. Isolation: 4 kV
  • Max. Continuous Service Temperature: 85°C
  • Strip Length: 9-10mm

Compact connector with levers

  • Solid conductor size 0.08 to 2.5 mm² /AWG 14
  • Stranded conductor size 0.08 to 2.5 mm² /AWG 14
  • Flexible conductor size 0.08 to 4 mm² /AWG 28 - 12

Features

  • Security - no loose wires, tape embrittlement danger, safe and transparent visible.
  • Convenience - a test hole, measure the voltage without removing tape.
  • Quick - direct plug, plug the wrong can be pulled out, followed again.
  • Reliable - Each contact shrapnel independent, fit different wire diameter, safety shorting.

Package included :

  • 3 WAY wire connector only.

Item color displayed in photos may be showing slightly different on your computer monitor since monitors are not calibrated same.
